Industrial valves play a crucial role in regulating and directing the flow of different liquids and gases in various industrial processes. They must be sturdy, corrosion-resistant & performed accurately to ensure safety and efficiency. One metal alloy that has gained increasing attention in the manufacturing of industrial valves is Stainless Steel 904L.
Stainless Steel 904L Valves is a super-austenitic material that contains molybdenum, nickel, and low carbon, making it ultra-resistant to corrosion. Its high nickel & other alloying elements make it highly resistant to acids containing chloride ions, such as sulfuric acid, phosphoric acid & hydrochloric acid also it makes it ideal for use in aggressive chemical environments.
Table Of content
SS 904L Industrial Valves have several benefits that make them an excellent choice for industrial applications. They offer durability, safety, and efficacy in regulating the flow of liquids and gases in various industrial processes. Stainless Steel 904L Ball Valves have superior corrosion resistance, high temperatures & pressure making them ideal for aggressive environments. They can withstand extreme cold and hot temperatures, making them suitable for cryogenic gas cooling applications. SS 904L Valves are also easy to maintain, and their unique properties make them stand out from other alloys.
904L Stainless Steel Valves have found uses in various industries. They are highly suitable for use in offshore oil and gas environments, chemical manufacturing plants, and pharmaceutical industries where hygiene, safety, and resistance to corrosion are critical. They are also widely used in producing and storing sulfuric acid, phosphoric acid & other strong acids.
904L SS Valves are perfect for nuclear power plants, desalination plants, and cooling systems, where extreme temperatures & pressures require valves that can withstand the rigours of industrial processes. The high-quality stainless steel products we provide at Global Steel include 316 Stainless Steel Valves, 304 Stainless Steel Valves and more.
Stainless Steel 904L Needle Valves make them an excellent choice for industrial applications. The metal alloy contains nickel & molybdenum, significantly enhancing its corrosion resistance. It is non-magnetic and does not interfere with electrical equipment or readings. High Quality Stainless Steel 904L Valves high tensile strength, flexibility & low carbon content make it ideal for high-pressure applications while reducing the risk of weld corrosion. We provide an extensive range of products, such as Alloy Steel A182 F91 Forged Fittings, Stainless Steel 321 Flanges and more.
SS 904L High Pressure Needle Valves are essential for various industries and applications. They offer benefits such as superior resistance to corrosion, high temperatures & pressures, making them ideal for harsh environments. SS 904L High Pressure Valves also have unique properties that make them easy to maintain and safe to use, while their high strength-to-weight ratio ensures durability and longevity.
Can Stainless Steel 904L valves be used in applications involving high-temperature chlorides?
Yes, Stainless Steel 904L valves can be used in applications involving high-temperature chlorides, as they exhibit resistance to both pitting and crevice corrosion in chloride-rich environments at elevated temperatures.
Can Stainless Steel 904L valves be used in applications where both pressure and temperature are extreme?
Yes, Stainless Steel 904L valves can be used in applications with extreme pressure and temperature conditions due to their combined resistance to corrosion and high mechanical strength.
What factors should be considered when selecting Stainless Steel 904L valves for an application?
Consider factors such as the corrosive media, operating temperature, pressure conditions, and industry regulations when selecting Stainless Steel 904L valves. Collaborate with valve manufacturers or experts for proper selection.
Standards | API 598 / BS EN 12266-1, ASME B 16.10, Sizes available on request API 600/BS1414, 1/8 to 1”, ASME B 16.34, ASME B 16.5, ASME B16.25 |
Sizes | Sizes available on Request, 1/8 to 1”, 1/2′ TO 14” |
Working Pressure | Valves are also available which could handle higher pressure, Up to 6000 PSIG |
End Connection | BSPT, Male and Female NPT, Male to Female, Socket Weld (SW) or Dual Ferrule Tube Connections, Female to Female |
Temperature Ratings | (232C)/Grafoil 700 F(371C), PTFE 450F |
Pressure Rating | 150#, 300#, 600#, 800#, 1500# |
Application | Power/ gas/ petroleum/ chemical/ metallurgy/ shipbuilding etc. |
Ends | Flange Ends, Screwed Ends,Socket Weld Ends |
Type | Ball Valves, Globe Valves, Check Valves, Needle Valves, Butterfly Valves |
Temperature Rating | (232C)/Grafoil 700 F(371C),PTFE 450F |
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Contact us to get a quick quote for your requirement.
We offer These Stainless Steel 904L Valves as per DIN, ISO, JIS or ANSI Standard.
Temp. °F | 150 | 300 | 400 | 600 | 900 | 1500 | 2500 |
---|---|---|---|---|---|---|---|
-20 to 100 | 275 | 720 | 960 | 1440 | 2160 | 3600 | 6000 |
200 | 230 | 600 | 800 | 1200 | 1800 | 3000 | 5000 |
300 | 205 | 540 | 720 | 1080 | 1620 | 2700 | 4500 |
400 | 190 | 495 | 660 | 995 | 1490 | 2485 | 4140 |
500 | 170 | 465 | 620 | 930 | 1395 | 2330 | 3880 |
600 | 140 | 435 | 580 | 875 | 1310 | 2185 | 3640 |
650 | 125 | 430 | 575 | 860 | 1290 | 2150 | 3580 |
700 | 110 | 425 | 565 | 850 | 1275 | 2125 | 3540 |
750 | 95 | 415 | 555 | 830 | 1245 | 2075 | 3460 |
800 | 80 | 405 | 540 | 805 | 1210 | 2015 | 3360 |
850 | 65 | 395 | 530 | 790 | 1190 | 1980 | 3300 |
900 | 50 | 390 | 520 | 780 | 1165 | 1945 | 3240 |
950 | 35 | 380 | 510 | 765 | 1145 | 1910 | 3180 |
1000 | 20 | 320 | 430 | 640 | 965 | 1605 | 2675 |
1050 | 20 [1] | 310 | 410 | 615 | 925 | 1545 | 2570 |
1100 | 20 [1] | 255 | 345 | 515 | 770 | 1285 | 2145 |
1150 | 20 [1] | 200 | 265 | 400 | 595 | 995 | 1655 |
1200 | 20 [1] | 155 | 205 | 310 | 465 | 770 | 1285 |
1250 | 20 [1] | 115 | 150 | 225 | 340 | 565 | 945 |
1300 | 20 [1] | 85 | 115 | 170 | 255 | 430 | 715 |
1350 | 20 [1] | 60 | 80 | 125 | 185 | 310 | 515 |
1400 | 20 [1] | 50 | 65 | 95 | 145 | 240 | 400 |
1450 | 15 [1] | 35 | 45 | 70 | 105 | 170 | 285 |
1500 | 10 [1] | 25 | 35 | 55 | 80 | 135 | 230 |
Size | L | a | b | W | H |
---|---|---|---|---|---|
1/8″ | 56 | 28 | 28 | 60 | 80 |
¼” | 56 | 28 | 28 | 60 | 80 |
3/8” | 56 | 28 | 28 | 60 | 80 |
½” | 58 | 28 | 28 | 60 | 81 |
¾” | 62 | 35 | 35 | 60 | 85 |
1” | 70 | 45 | 45 | 70 | 100 |
Port Size (BSP) | Media Pressure | Media Temperature | CV |
---|---|---|---|
1/8″ | 0 to 408 Bar | -20°C to 230°C | |
¼” | 0 to 408 Bar | -20°C to 230°C | 0.4 |
3/8” | 0 to 408 Bar | -20°C to 230°C | 0.4 |
½” | 0 to 408 Bar | -20°C to 230°C | 0.6 |
¾” | 0 to 408 Bar | -20°C to 230°C | 1.6 |
1” | 0 to 408 Bar | -20°C to 230°C | 2.5 |
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
SS 904L | 0.020 max | 2.00 max | 1.00 max | 0.040 max | 0.030 max | 19.00 – 23.00 | 4.00 – 5.00 max | 23.00 – 28.00 | 1.00 – 2.00 |
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35 % |
